GZ-200 METAL DOCTOR BLADE

Gold Coated Doctor Blades
GZ-200 (20MC1 Carbon Steel)
  • GZ-200 (20MC1 Carbon Steel)
  • GZ-200 (20MC1 Carbon Steel)
  • GZ-200 (20MC1 Carbon Steel)
Request a Quote
Blade Edge Shapes
  • Lamella Blade Edge
  • Bevel Blade Edge
Specifications
Width range: 10mm-60mm
Width tolerance: ±0.1mm
Thickness range: 0.152mm-0.203mm
Thickness tolerance: ±0.005mm
Hardness: 580-600HV
Tensile strength: 1850-2100Pa
Straightness: ≤0.5mm/3000mm
Coating thickness: 10-15μm
Dimensions
  • 10mm×0.15mm×100m
  • 20mm×0.15mm×100m
  • 20mm×0.2mm×100m
  • 30mm×0.15mm×100m
  • 30mm×0.2mm×100m
  • 35mm×0.15mm×100m
  • 35mm×0.2mm×100m
  • 40mm×0.15mm×100m
  • 40mm×0.2mm×100m
  • 50mm×0.15mm×100m
  • 50mm×0.2mm×100m
  • 60mm×0.15mm×100m
  • 60mm×0.2mm×100m
The listed specifications are standard sizes. Customized dimensions can be provided upon request to meet specific printing requirements.
Application Processes

Gravure printing, Flexo printing, Roller Coating, Adhesive coating, Lamination

Ink adhesion and blade contamination can affect print consistency, especially when working with high-viscosity or coarse-particle inks. To improve performance and longevity, these doctor blades incorporate a golden-colored coating that enhances corrosion resistance and anti-adhesion properties. With a 10-15μm high-hardness coating, these metal doctor blades minimize ink buildup on their edge, reducing streaks and surface irregularities. The enhanced coating durability ensures clean ink transfer and stable print quality, even under demanding printing conditions. The improved surface protection also helps extend the lifespan of both the blade and the printing plate.

Find the Best Doctor Blade for Your Printing Needs. Contact Us Now!
Email: 18255555333@163.com
Mobile: +86-18255555333
Why choose coated doctor blades?

These blades provide enhanced wear resistance and reduced ink adhesion, ensuring effective performance with sticky, high-viscosity inks. The specialized coating helps prevent ink buildup, resulting in consistent print quality and less frequent maintenance.

What are the advantages of coated doctor blades?

The enhanced coating provides better resistance to corrosion and ink contamination, ensuring a more stable ink flow throughout the printing process. By reducing ink accumulation, these blades help prevent print defects and protect the anilox roller.

Which blade is best for high-viscosity, coarse-particle inks while maintaining print quality?

For inks with high pigment concentration and larger particles, the GZ-200 gold-coated doctor blade is the best option. Its reinforced coating improves durability and anti-adhesion performance, ensuring clean ink transfer and prolonging anilox roller life while maintaining print sharpness.
